CNSMT Automatic SMT assembly line PCB Magazine loader Dual gauge closing machine
Quick Detail
Feature
| Product Name: | SMT LOADER AND UNLOADER |
| Used for: | smt assembly full line |
| Warranty: | 1 Year |
| Shipment | by air |
| Delivery Time: | 1-2Days |
| Our Main Market | Whole of the world |
Application
3. At the same time, we expect that China's SMT industry will still be mainly concentrated in the Yangtze River Delta region, the Pearl River Delta region and the Bohai Rim region in the next five years. However, the proportion of the Yangtze River Delta region in China's SMT industry will start to rise rapidly from 2007 and reach 43.9% in 2009. Although the proportion of the Pearl River Delta region dropped to 47.O%, but still occupy the top position. In addition, the SMT industry in the Bohai Rim has also developed rapidly. The rapid growth of the SMT industry in the Yangtze River Delta region is mainly due to the transfer of global SMT industry, especially the transfer of SMT production. For historical reasons, the basis for the development of equipment manufacturing in the Yangtze River Delta region is relatively strong. At the same time, the production of high-end electronic products such as notebooks and mobile phones in the Yangtze River Delta region is well-developed. In addition to the unique geographical advantages of the Yangtze River Delta region, the Yangtze River Delta region will undergo a major transfer of the global SMT industry in 2007. Accept a large part of the proportion. However, for the Pearl River Delta region, due to its development in the past few years, its SMT industry has formed a relatively complete industrial chain and supporting environment for the industry, so the Pearl River Delta region also has obvious advantages in undertaking industrial transfer.
4. From the perspective of the industry's own development cycle, although China's SMT industry is still in its early stages of development, it has already shown great vigor. At the same time, the SMT industry is an important basic industry, which is of great significance in promoting China's electronic information industry manufacturing restructuring and industrial upgrading. Promoting the rapid and sound development of China's SMT industry requires the cooperation of all sectors in the industry.
| Specification | SMT PCB automatic magazine loader | L PCB machine | PCB buffer for AOI SPI | pcb loader stack machine |
| Power supply | AC 220V/ 50/60Hz | |||
| Air supply | 5 kg f/cm² | |||
| PCB size (mm) | 330*50~250 | 445*50~330 | 530*50~390 | 535*50~460 |
| PCB transport direction | Customize left to right or right to left | |||
| Magazine size (mm) | 335*320*565 | 460*400*565 | 535*460*565 | 535*530*565 |
| Step pitches | 10,20,30,40mm choosable | |||
| Transport speed | 10m/ min | |||
| Transport height | 900 ± 20 mm or 950 ± 20 mm, customizable. | |||
| Main motor power | 220W | |||
| Machine size | 1750*765*1250 | 1920*845*1250 | 2160*910*1250 | 2160*975*1250 |
| Weight (kg) | 230 | 260 | 290 | 320 |
| Control panel | Touch screen |
