SMT Pick And Place Machine Mounter Weight 1750kg Pressure 50NL/min Size 370 X 1 for Precise Component Placement

The HANWHA HM520NEO HS MF NEW P&P Machine is an Automatic Pick And Place Machine designed for high-performance placement accuracy, speed, and reliability. With a placement accuracy of ±28μm, this machine ensures precise component placement on PCBs.

Equipped with advanced technology, this HANWHA Pick And Place Machine offers a productivity rate of up to 85,000 CPH, making it ideal for high-volume production environments. Whether handling components from 0201 to □ 6 mm, this machine delivers consistent and accurate results.

One of the key features is its ability to handle PCB thickness ranging from 0.38mm to 4.2mm. This flexibility allows for versatile application across various industries and production requirements.

Designed for seamless operation, this machine is equipped with Smart Factory Software Solutions, enabling unmanned, non-stop, and zero-defect production. This integration enhances efficiency and productivity while ensuring consistent quality output.

• Product Name: SMT Pick And Place Machine
• Accuracy Comparison:
  • HM520 NEO HS: ±25 μm @ Cpk ≥ 1.0 (Chip)
  • HM520 NEO MF: ±40 μm @ Cpk ≥ 1.0 (Chip) / ±30 μm @ Cpk ≥ 1.0 (IC)
• Chip Speed: 85000CPH (max)
• Component Range Comparison:
  • HM520 NEO HS: 0201 ~ □ 6 mm
  • HM520 NEO MF: 0402 ~ □ 55 mm
• Pressure: 0.5-0.7MPa (5-7kgt/cm2) 350NL/min, 50NL/min
• Operation: Automatic

The HANWHA HM520NEO HS MF NEW P&P Machine is designed for high-precision electronic component assembly. With exceptional accuracy levels and rapid speed, it is suitable for various manufacturing applications including consumer electronics, automotive components, medical devices, and telecommunications equipment.

• Initial machine installation and setup assistance
• On-site training for machine operators
• Remote troubleshooting and diagnostics
• Regular maintenance and calibration services
• Software updates and technical documentation
• 24/7 customer support hotline

The SMT Pick And Place Machine is carefully packaged in a sturdy cardboard box with foam inserts for protection during transit. Orders are shipped within 1-2 business days via reliable courier service with tracking number provided.
