Advanced Automatic Pick Place Machine with 2 Gantry * 10 Spindle / 100 and AC 200/208/220/240/380/415V Power Supply

The HANWHA XM520 NEW P&P Machine is an advanced Automatic Pick & Place Machine designed for high-speed and precise component placement in SMT assembly lines. Equipped with cutting-edge technology, this machine offers exceptional performance and efficiency to meet the demands of modern electronic manufacturing.

The HANWHA XM520 features 2 Gantry units with a total of 10 spindles, allowing for simultaneous operation and increased productivity. The machine boasts a spindle speed optimized for high-volume production, achieving an impressive placement rate of up to 100,000 components per hour (CPH).

With a compact design, the HANWHA XM520 has dimensions of L 1,430 X D 1,900 X H 1,994, making it suitable for various factory layouts and space constraints. Despite its powerful capabilities, this SMT Pick And Place Machine has a manageable weight of 1820kg, ensuring ease of installation and mobility within the production facility.

As a leading manufacturer in the industry, HANWHA has leveraged its expertise to create the XM520 model, incorporating innovative features and reliable performance. This machine is ideal for electronics manufacturers looking to streamline their production processes and achieve high levels of accuracy and efficiency.

• Product Name: SMT Pick And Place Machine
• Accuracy: ±22 μm @ cpk ≥ 1.0
• PCB Thickness: 0.38-4.2mm
• Pressure: 0.5-0.7MPa (5-7kgt/cm2) 350NL/min, 50NL/min
• Mounter Size: L 1,430 X D 1,900 X H 1,994
• Number Of Mounting Shafts: 2 Gantry * 10 Spindle / 100,000 CPH (Optimum)

JUKI's Desktop SMT Pick And Place Machine, including the models KE2050M and KE2050CM, is a versatile and efficient solution for a wide range of product application occasions and scenarios. With its CE certification and origin from Japan, this machine guarantees high quality and reliability.

The minimum order quantity for this ASM Pick And Place Machine is 1, and the price is negotiable, making it accessible to both small-scale and large-scale manufacturing operations. Payment terms such as T/T, Paypal, and Western Union are all allowed, providing flexibility for customers.

With a supply ability of 10 units per day and a quick delivery time of 5-7 work days, the JUKI SMT Pick And Place Machine ensures that production lines can operate smoothly and efficiently. The machine is carefully packaged in wooden boxes to prevent any damage during transportation.

The dimensions of the machine are 1,430 x 1,900 x 1,994 mm, making it compact and suitable for various factory layouts. It offers a chip speed of up to 100,000 CPH (max), enabling fast and precise component placement.

Operating at a pressure of 0.5-0.7MPa (5-7kgf/cm2) with air consumption rates of 350NL/min and 50NL/min, this machine is designed for optimal performance. The HANWHA brand ensures top-notch quality and reliability.

With a component range of 0201 to □22 mm (Fly) and up to L150 x 55 mm (Stage), the JUKI Desktop SMT Pick And Place Machine is suitable for a wide variety of electronic components and circuit board sizes. Whether it's for prototyping, small batch production, or full-scale manufacturing, this machine offers the precision and efficiency required for modern electronics assembly processes.

• On-site installation and training services to ensure proper setup and operation of the machine.
• Remote technical support for troubleshooting issues and providing guidance on usage and maintenance.
• Regular software updates and upgrades to enhance functionality and address any potential issues.
• Access to a dedicated support team for any questions or concerns regarding the product.
• Comprehensive warranty coverage to protect against any defects or malfunctions.

Our SMT Pick And Place Machine is carefully packaged to ensure safe delivery to our customers. The machine is securely placed in a sturdy cardboard box with ample padding to prevent any damage during transportation.

For shipping, we partner with reliable carriers to ensure timely and secure delivery. Each package is labeled with the necessary shipping information and tracking details are provided to the customer for easy monitoring of the shipment.
