Specification:
| Yamaha YS24 parameters |
| Small ultra high speed modular placement machine YS24 |
| Top-level placement capability in a universal placement machine 72,000 CPH (0.05 sec/CHIP) |
| The maximum number of feeders that can be installed (8mm tape reel) 120 kinds |
| World's top area productivity 34kcph/m2 |
| Supportable components 0402~32×32mm |
| Dimensions: L1, 254 × W1, 687 × H1, 445mm; L1, 544 (lengthened conveyor end) × W1, 687 × H1, 445mm |
| Weight: about 1,700kg |
| Yamaha YS24X parameters |
| Top-level placement capability in a universal placement machine 54,000 CPH (0.067 sec/CHIP) |
| The maximum number of feeders that can be installed (8mm tape reel) is 96 (62 types with sATSII) |
| Supports automatic replacement tray feeder (30 types of JEDEC trays) sATSII |
| Supportable components, height 0402~45×100mm, H15mm |
| Dimensions: L1, 254 × W1, 687 × H1, 445mm; host only; L1, 544 (longer conveyor end) × W2, 020 × H1, 545mm |
| Weight: about 1,700kg (host only); about 1,890kg (when equipped with sATSII) |
