High Speed Automatic Insertion Machine , Dip Equipment Led Insertion Machine

  • High Speed Automatic Insertion Machine , Dip Equipment Led Insertion Machine
Place of Origin China
Brand Name cnsmt
Certification CE
Model Number Auto Insertion Machine
Minimum Order Quantity 1
Price negotiation
Packaging Details box
Delivery Time 5-7 work days
Payment Terms T/T, Western Union
Supply Ability 100pcs/day
Product Details
Brand Cnsmt MODEL Auto Insertion Machine
Weight 1130KG Lead Time IN Stork
Packing BOX CONdition Working
P/N Cnsmt-ai035 PAYMENT TERM T/T, Paypal, Westernunion Are All Allowed
High Light

conformal coating equipment

,

bga rework machine
Leave a Message
Product Description

AVK3 RH2 Auto Insertion Machine HIGH Speed dip equipment stable and high quality


Quick Detail



Theoretical velocity 7000-9000 points / hours
Insertion loss rate Less than 500PPM
Insertion direction 0-360 degrees (increments of 1 degrees)
Substrate size Minimum 80mm * 100mm, maximum 480mm x 3000mm
Substrate thickness 1-2.5mm
Plug-in component object 6*6-5H right angle light touch switch (4.5*6.5mm)
Number of plug-in axes The 2-3
Machine size (long * width * high) 2310mm/1400 x 1925mm
Machine weight 1790kg (1 working heads)
Use power 220V, AC (Dan Xiang); 50/60HZ, 1.0KVA, 967W (energy saving)
System protection Uninterruptible power supply (UPS) configuration
Use power 960W
Use of air pressure 0.4-0.6Mpa
Gas consumption 0.3 cubic / minute (dry gas)
Use of ambient temperature 5-26 degrees
Machine noise 55 decibels
Hole position correction method Machine vision system, multipoint MARK visual correction
driving system AC servo, AC motor
Data input mode USB interface input (EXCEL document format)
Control system Chinese operation interface (WINDOWS system control platform) LCD monitor
Worktable operation mode From left to right, from right to left
Transmission mode of PCB Manual / automatic optional


Feature

Product Name: smt   Auto Insertion Machine
Used for: smt assembly full line
Warranty: 1 Year
Shipment by air
Delivery Time: 1-2Days
Our Main Market Whole of the world


Packaging details:foam and carton
Delivery time:Within 1~3 working days
Shipment
1. We ship to world wide
2. Most orders ship within 1~7days after payment
3. Item shipped from china mainland using airmail by EMS, UPS, DHL, TNT or Hong Kong post, we accept the customer’s shipping request
4.100%T/T before shipment, after we shipped the goods, we will email you the shipping information
5.WE sell and buy used equipment long-term
High Speed Automatic Insertion Machine , Dip Equipment Led Insertion Machine 0

This machine is mainly used in large devices, special-shaped devices and plug-ins in existing market plug-ins.
This machine is composed of feeding structure, plug-in robot, foot bending, feeding plate mechanism and controller.
*: each motion mechanism adopts a high precision servo mechanism, and camera induction is used to ensure the stability and accuracy of the machine.
Man-machine interface control device: to operate the touch screen through the program written in PLC to start and stop the machine's processing sequence, and to set and modify the processing parameters.
d."
