YAMAHA cylinder quick coupler
,10x5 straight quick coupler
,YAMAHA spare parts coupler
-
Place of OriginJAPAN
-
Brand NameYAMAHA
-
CertificationCE-9090-41J062
-
Model NumberKHY-9090-41J062
-
Minimum Order Quantity1 set of machine or mixed order is also acceptable Transport: By Bulk or Containers
-
PriceNegotiable
-
Packaging DetailsStandard export boxes and sturdy hardwood packages are both options
-
Delivery Time1-2 Working days
-
Payment TermsL/C, D/A, D/P, T/T, Western Union,MoneyGram
9090-41J062 10×5 Cylinder Straight Quick Coupler
9090-41J062 10×5 Cylinder Straight Quick Coupler
Model 9090-41J062 is a dedicated 10×5 straight quick pneumatic connector designed specifically for Yamaha chip mounters. This precision component features nickel plating for superior rust resistance and high-performance sealing rings that maintain excellent airtightness without pressure leakage.
Manufactured to original dimensions for perfect fit, this quick coupler locks automatically for tool-free installation. Compatible with YS12 and YG12 models, it stabilizes pneumatic clamping, reduces air pressure malfunctions, and enables easy maintenance with extended service life.
Core Functions
- Designed for Yamaha series mounter pneumatic circuits, this 10×5 cylindrical quick connector rapidly connects air cylinders and tubes to deliver compressed air for edge clamping, feeding, and other pneumatic mechanisms
- Self-locking quick-plug design enables tool-free assembly and disassembly while built-in sealing structure prevents air leakage and stabilizes pressure output
- Secures air circuit joints and cushions pressure fluctuations during pneumatic start/stop cycles, preventing loose clamping and equipment jams caused by unstable air pressure
Parameter Specifications
| Part Number | 9090-41J062 |
| Product Name | Cylinder Joint Connected to Fast Cylinder |
| Brand | YAMAHA |
| Applicable Models | Yamaha YS12, YG12 SMT machine pneumatic clamp, Feida pneumatic components |
| Supplier | Factory direct sales |
| Condition | Brand new original |
| Interface Specification | 10 × 5 cylinder joint connected to quick cylinder |
| Suitable Pipe Diameter | 5mm outer diameter trachea |
| Structural Form | Direct insertion self-locking, tool free insertion and removal |
| Surface Treatment | Rust resistant electroplating, resistant to corrosion in pneumatic environments |
| Sealing Structure | Built in rubber sealing ring, high-pressure airtight and leak proof |
| Compatible Equipment | Yamaha YS12, YG12 surface mount machine pneumatic clamp, Feida pneumatic components |
| Working Medium | Compressed air, compatible with equipment standard working pressure |
Product Promotion
CNSMT specializes in producing 9090-41J062 cylindrical quick-release cylinder connectors compatible with Yamaha YS12 and YG12 mounters. With precision sealing and nickel-plated anti-rust treatment, our brand-new original parts are well-stocked for global supply at cost-effective prices. We provide comprehensive after-sales warranty to stabilize pneumatic system operation and lower breakdown losses.
