FUJI A10397 NXT Second-generation Track Fiber Amplifier SMT Spare Parts

FUJIA10397 NXT second-generation track fiber amplifier
Our company has been in operation for 11 years and will definitely be your best choice with guaranteed quality and fast delivery

Product Introduction – FUJI A10397 NXT Second-Generation Track Fiber Amplifier

Part Number: A10397

Product Name: Track Fiber Amplifier

Category: Optical Sensor / Signal Amplifier Module

Applicable Models: FUJI NXT II (Second Generation) Placement Machines

Product Overview

The FUJI A10397 Fiber Amplifier is an advanced optical signal processing unit used in FUJI NXT second-generation track systems. It functions as the core signal-processing component for fiber optic sensors that detect PCB presence, position, or movement along the conveyor (track).

This module ensures precise and reliable detection by amplifying the light signals received through the fiber optic sensor heads and converting them into digital signals used by the machine’s control system.

Key Features

High-Precision Detection
Enables accurate monitoring of PCB location and track status.

Supports Fiber Optic Sensors
Compatible with fiber heads commonly used in NXT II conveyor systems (e.g., reflective or through-beam types).

Fast Response Time
Ensures real-time signal transmission to the main controller for high-speed SMT operation.

Modular Installation
Designed for easy integration into the machine’s track section or I/O block.

Digital/Analog Output
Provides clear signal output for machine logic or alarms.

Applications

Track (conveyor) edge detection
PCB in/out signal verification
Optical sensor signal amplification
Presence/absence detection at stop gates or buffer zones

Related Components

Technical Specifications (Typical)

Input: Fiber optic signal (from sensor head)
Output: Digital ON/OFF or analog voltage (depends on model)
Voltage: 24 VDC (machine standard)
Mounting: DIN rail or panel mount inside track unit
Response Time: ≤ 1 ms
Indicators: LED status lights for signal/power

Ordering Notes

Verify compatibility with NXT II track system layout and sensor head model.
Use OEM parts to ensure detection reliability and system integration.
Do not substitute with generic fiber amplifiers without confirming specifications.

Related Accessories – FUJI A10397 Fiber Amplifier

Notes:

The fiber sensor head and amplifier must be compatible in terms of signal type and sensing range.
Ensure all components follow the FUJI NXT II track electrical and mechanical standard.
Clean sensor heads regularly to maintain detection accuracy.

Related Part Numbers – FUJI A10397 Fiber Amplifier System

Notes:

Sensor head part numbers (e.g. FD-V11) may vary depending on detection type (slot, reflective, through-beam).
When replacing or adding sensors, confirm voltage, wiring type, and connector compatibility with FUJI’s NXT system.
Use original FUJI or compatible high-quality brands like Panasonic or Keyence for best results.

FAQ Guide – FUJI A10397 NXT Second-Generation Track Fiber Amplifier

1. What is the function of the FUJI A10397 fiber amplifier?

Answer:
The A10397 fiber amplifier is used in FUJI NXT II (second-generation) SMT machines to amplify and process optical signals from a fiber sensor head. It converts light signals into electrical signals to detect the presence, position, or movement of PCBs along the conveyor (track system).

2. What components does it work with?

Answer:
It works with the following parts:

Fiber optic sensor head (e.g., through-beam or reflective type)
Track control PCB (receives output signals)
Mounting bracket (holds the sensor in position)
Signal and power cables

See related part numbers like:

FS-V21G – Fiber amplifier body
FD-V11 / FT-V21 – Sensor head
A40431 – I/O cable

3. Where is the fiber amplifier installed?

Answer:
It is installed inside or near the NXT II track module, usually mounted on a DIN rail or bracket next to the fiber sensor head location.

4. What types of detection tasks does it support?

Answer:

PCB entry/exit detection
Board stop control
Track congestion monitoring
Component or carrier presence sensing
It is critical for precise synchronization of PCB flow during high-speed assembly.

5. Is the A10397 a standalone unit or part of a system?

Answer:
It is part of a fiber sensing system and must be used together with a compatible fiber head and connected to the main track controller PCB.

6. How do I know if the fiber amplifier is malfunctioning?

Answer:
Common symptoms:

LED status light not responding
Incorrect or no signal sent to the control board
False detection or missed PCB events
Sensor head shows signal loss despite a clear target

7. How do I replace or calibrate the amplifier?

Answer:

Power down the machine before handling.
Replace with the same part number (A10397) or confirmed equivalent.
Use the adjustment buttons (if applicable) to tune signal sensitivity.
Confirm correct wiring and test signal response with a known trigger object.

8. Is it compatible with all Fuji systems?

Answer:
No. The A10397 is specifically designed for NXT II second-generation systems. It is not directly compatible with NXT III or earlier versions unless retrofitted or approved by FUJI.

9. What are the installation and electrical specs?

Answer:

Voltage: Typically 24VDC
Output: Digital (ON/OFF) or analog signal
Mounting: DIN rail / bracket
Response time: ≤ 1 ms
Indicator lights: Show signal strength and power status

10. Where can I buy or get support for A10397?

Answer:

From authorized Fuji SMT distributors or third-party SMT parts suppliers
Confirm machine compatibility and sensor head match before ordering
Support available from Fuji technical representatives or service engineers
