FUJI XK05780 XS Axis Interlocking Board – Product Description

Overview

The FUJI XK05780 is an XS-Axis Interlocking Board, also known as the XS Interlock Board, designed for use in FUJI NXT series SMT machines. It plays a key role in coordinating mechanical and electrical interlock functions along the XS (X-Sub) axis, ensuring safe and synchronized movement of the placement head or table mechanism.

Key Features
Controls interlock signals for XS-axis operation Ensures synchronized motion between mechanical modules Provides position detection, safety signal processing, and system coordination Includes interface for signal input/output, limit switches, and sensors Supports fault detection and interlock fail-safe conditions

Applications

Used in FUJI NXT series machines (check model compatibility: e.g., NXT II, NXT III)
Installed in the control system for the XS-axis motion unit
Coordinates movement between placement heads, feeders, and transport systems
Essential for systems with multi-head, multi-station interconnects

Technical Specifications (Typical)

Benefits

Enhances machine safety and coordination
Maintains precise positional synchronization across modules
Modular design for easy replacement or servicing
Supports FUJI’s high-speed and high-accuracy placement environments

Included

1 × XK05780 XS Interlock Board (Original FUJI part)
May include standard harness or installation guide depending on supplier

Related Accessories – FUJI XK05780 XS-Axis Interlock Board

Optional or Supporting Components

FUJI XK05780 XS Interlock Board – Related Part Numbers

Other Potentially Compatible or Replacement Parts

FAQ Guide – FUJI XK05780 XS Axis Interlocking Board

General Information
Q1: What is the FUJI XK05780 XS-Axis Interlock Board?

A:
The XK05780 is a signal control PCB used in FUJI NXT SMT machines. It manages interlock signals for the XS-axis (a sub-axis of the main X-axis), ensuring that motorized movements along this axis are safe, coordinated, and properly Q2: Which FUJI systems use this board?

A:
It is primarily used in FUJI NXT series machines, particularly in configurations where multi-head, multi-module coordination is required. It may be present in NXT II, III, and IV models depending on machine layout.

Functions & Features
Q3: What does the XS Interlock Board control?

A:

Signal interlocking for XS-axis motion systems
Limit switch monitoring for safety stops
Coordination between placement head units and feeder modules
Fault detection and safe-stop triggers for axis overrun or misalignment

Q4: What happens if the interlock board fails?

A:
Failure can cause:

Inability to initialize XS-axis
Safety alarms during startup or homing
Axis movement restriction (machine may enter safe mode)
In this case, the board should be tested and, if needed, replaced.

Installation & Maintenance
Q5: Is it user-serviceable?

A:
Yes, it is modular and designed for field replacement. Make sure to:

Power down the machine
Disconnect signal/power harnesses
Replace with an identical part (XK05780)
Verify axis initialization post-installation

Q6: How do I know if the board is working?

A:

Some units include LED indicators showing status
The main control system will confirm interlock OK during startup
Use diagnostic tools or software to trace signal flow

Q7: Does firmware or software affect this board?

A:
Yes. The board interacts with the main controller and may require firmware compatibility. Use only FUJI-approved versions and always check for required updates if replacing with a newer board.

Troubleshooting

Related Parts

Best Practices

Use original FUJI parts only to maintain machine safety
Always power down before handling interlock wiring or boards
Perform routine diagnostic tests during scheduled maintenance
Label and document I/O connections before board swap
