KHY-M71CA-00 YAMAHA YS12 24 vacuum detection cover
KHY-M71CA-00 YAMAHA YS12 24 vacuum detection cover
Specification:
| KH5-M7182-C00 Filter filter cotton YV88XG filter cotton YV88X filter rod |
| K46-M8527-C00 K46-M8527-C0X YAMAHA filter cotton 5322 360 20081 |
| K46-M8527-C0X Part nr.: 5322 360 20081 YAMAHA original authentic filter cotton |
| KM5-M7174-G0x YAMAHA filter cotton plug FILTER CAP filter white plug |
| KHY-M7155-01 FILTER CAP YS12 solenoid valve vacuum air seat filter cover cup filter cotton plug |
| KHY-M7155-00 FILTER CAP YS12 YG12 YS24 YS100 solenoid valve filter cotton cover |
| 5322 462 11024 YAMAHA filter cotton cover |
| KM5-M7174-G0 KM5-M7174-F0 5322 462 1102 YAMAHA filter cotton stopper |
| K46-M8527-C0X K46-M8527-C0 YAMAHA YV100II YV100X XG Filter cotton |
| K46-M8527-C0X C0 YAMAHA filter cotton core rod YV100X XG YG12 YS12 universal |
| KG7-M8501-40X AIR FILTER ELEMENT YAMAHA Air Filter Filter Cotton |
| K46-M8527-C0 YS12 YS12F YG12F YG12 YS24 YS100 YS88 filter cotton |
| K46-M8527-C0 KHY-M8527-B0X YG12 YS12 YS24 YS100 small filter cotton |
| KLW-M8527-00 YSM10 YSM20 YAMAHA machine filter cotton filter rod dust filter |
| K46-M8527-COX K46-M8527-C00 YAMAHA original filter cotton FILTER ASSY |
| 5322 480 10106 Mounter Filter Cotton Filter Rod Filter Filter |
| Filter cap Part nr.: 9498 396 02341 |
| K87-M2160-00X BACK PLATE ASSY 1 |
| 2 K87-M2166-00X GUIDE PLATE 1 |
| 3 K87-M2191-00X DRIVE ROLLER UNIT 1 |
| 4 K87-M2192-00X INDENTATION LEVER ASSY 1 |
| 5 K87-M2196-00X SUB LEVER ASSY 1 |
| 6 K87-M2199-00X DRIVE GEAR ASSY 1 |
| 7 K87-M117B-00X PLANE WASHER 1 |
| 8 K87-M11BB-00X SCREW,FLAT HEAD + IB 1 |
| 9 K87-M219C-00X LEVER METAL ASSY 1 |
| 10 K87-M11B2-00X SCREW,FLAT HEAD + 2 |
| 11 K87-M219G-00X DRIVE ROLLER 1 |
| 12 K87-M119J-00X THRUST WASHER 1 |
| 13 K87-M219K-00X SPRING 1 |
| 14 K87-M219L-00X IDLE ROLLER ASSY 1 |
| 15 K87-M117B-00X PLANE WASHER 2 |
| 16 K87-M11BB-00X SCREW,FLAT HEAD + IB 2 |
| 17 K87-M119P-00X SPRING 1 |
| 18 K87-M21A1-00X LOWER GUIDE PLATE 1 |
| 19 K87-M21A3-00X LOWER GUIDE PLATE 1 |
| 20 K87-M111N-00X SCREW,PAN HEAD + 6 |
| 21 K87-M11BE-00X PLANE WASHER 6 |
| 22 K87-M11B9-00X CIRCLIP E |
| KV8-M7101-00X HOUSING HEAD 1 |
| 2 KG2-M7181-00X PACKIN MYA 4 4 |
| 2-1 90990-22J001 PACKIN MYA 4 4 |
| 3 KM1-M7140-00X PACKING 4 MYR-6 |
| 3-1 90990-22J003 PACKING 4 MYR-6 |
| 4 KM1-M7141-00X PACKING 4 MYA-10A |
| 4-1 90990-22J002 PACKING 4 MYA-10A |
| 5 KV8-M7103-00X PISTON,PLUG 4 |
| 6 KV8-M71Y5-00X PACKING 4 MYA-12.5 |
| 6-1 90990-22J015 PACKING 4 MYA-12.5 |
| 7 K65-M257M-00X O-RING 3 4 S12.5 |
| 7-1 90200-01J125 O-RING 4 S12.5 |
| 8 KM1-M7140-00X PACKING 4 MYR-6 |
| 8-1 90990-22J003 PACKING 4 MYR-6 |
| 9 KV8-M7103-10X PLUG 4 |
| 10 KV8-M7104-00X PISTON 8 |
| 11 KM1-M7107-00X PACKING 8 LO43165 |
| 11-1 90990-22J006 PACKING 8 LO43165 |
| 12 KM1-M7141-00X PACKING 16 MYA-10A |
| 12-1 90990-22J002 PACKING 16 MYA-10A |
| 13 KV8-M71RJ-00X COLLAR,BRG. 4 |
| 14 93210-02518 O-RING 4 |
| 14-1 90990-17J003 O-RING 4 |
| 15 KG7-M7137-A0X LEAF SPRING 8 |
| 16 KG7-M7169-00X SCREW 8 |
| 17 KG7-M7170-00X WASHER 8 |
| 17-1 90990-28J002 WASHER PLAIN 8 2003.03.28 M330113 |
| 18 KM9-M7106-80X NEEDLE PIN 4 |
| 18-1 90990-19J002 NEEDLE PIN 4 2001.12.25 M1Y0079 |
| 19 KM1-M7106-90X SPG. NOZZLE 4 |
| 20 KV8-M7106-00X BALL SPLINE 4 |
| 21 KV8-M7106-70X SHAFT,NOZZLE 4 |
| 22 KV8-M7109-00X COLLAR 1,HEAD 4 |
| 23 KJ2-M7157-00X BRG 8 MF128ZZS |
| 23-1 90933-03J128 BRG 8 MF128ZZS |
| 24 KH4-M7133-00X BRG 8 MR128ZZS |
| 24-1 KJ2-M7157-00X BRG. : MF128ZZS X1 1998.12.16 M010097 |
| 24-2 90933-03J128 BRG 8 MR128ZZS |
| 25 KM1-M7109-00X PULLEY 8 |
| 26 KV8-M7154-00X SPG.RETURN 4 |
| 27 KV8-M7108-00X NUT 8 |
| 28 KM1-M7155-00X BRG 8 604ZZ |
| 28-1 90933-02J604 BRG 8 604ZZ |
| 29 99001-03600 CIRCLIP 8 |
| 29-1 90440-01J030 CIRCLIP 8 2001.12.28 M1Y0129 |
| 30 KU1-M7152-00X WASHER 1 THURUST 8 |
| 31 KV8-M7110-00X COLLAR 2,HEAD 4 |
| 32 KV8-M71X2-00X SPG.RETURN 4 |
| 33 KV8-M7106-51X BALL SPLINE 4 |
| 33-1 KV8-M7106-52X BALL SPLINE 1 Z3 2000.10.02 M030184 |
| 34 KV8-M71V8-00X O-RING 4 |
| 34-1 90200-02J030 O-RING 4 |
| 34-2 Delete 2004.04.11 M040054 |
| 35 KV8-M71X1-00X SPG.LOCATE 4 |
| 36 KV8-M71R1-01X SHAFT 1 4 |
| 36-1 KV8-M71R1-XXX SHAFT 1 SEL 1 Z3 2000.6.7 M030184 |
| 37 KV8-M71R2-01X BLOCK,STOPPER 4 |
| 38 2002.07 |
| 39 KV7-M71M6-01X SCREW,NOZZLE 8 |
| 39-1 KV7-M71M6-01X SCREW,NOZZLE X1 1999.11.1 M980007 |
| 40 KV8-M71R5-01X PIN,LOCATE 4 |
| 40-1 KV8-M71R5-02X PIN,LOCATE 4 2000.03.31 M030184 |
| 41 KV8-M71R6-01X HOLDER,INDEX 4 |
| 41-1 KV8-M71R6-02X HOLDER,INDEX 4 2000.03.31 M030184 |
| 42 KV8-M71R9-00X CAM 8 |
| 43 KV8-M71RA-00X BEVEL 4 GEAR 1 |
| 44 KV8-M71RB-A0X BEVEL GEAR ASSY 4 GEAR 2 2002.07 |
| 45 KV8-M71RC-00X PIN,CAM 8 |
| 46 KV8-M71RD-00X CIRCLIP 16 E0.8 |
| 46-1 90440-10J008 CIRCLIP 16 |
| 47 KV8-M71RE-00X WASHER 4 |
| 48 99009-12800 CIRCLIP 4 |
| 49 KV8-M71U0-01X NOZZLE ASSY 4 |
| 49-1 KV8-M71U0-11X NOZZLE ASSY 4 2002.09.10 M280135 |
| 50 KV8-M71R7-00X HOLDER,BRG. 4 |
| 50-1 KGB-M71R7-00X HOLDER,BRG. 4 2001.02.14 M120092 |
| 51 KV8-M71R8-00X COLLAR,BRG. 4 |
| 52 K47-M7143-00X BEARING 4 |
| 52-1 KV8-M71RG-00X BEARING 4 X1 M920013 |
| 52-2 90933-01J801 BEARING 4 |
| 53 KV8-M7111-00X PULLY,POST 1 |
| 54 KV8-M7113-01X RING,DOG 1 |
| 54-1 KV8-M7113-01X RING,DOG 1 Y3 2000.1.24 M9Y0069 |
| 55 KV8-M7115-00X SHAFT 1,TENSION 2 |
| 56 KV8-M7116-00X PULLY 2 1 |
| 57 KV8-M7117-00X BLOCK,ADJUST 1 |
| 58 KV8-M7119-00X BLOCK,ADJUST 1 |
| 59 KV8-M7124-00X PLATE,R SENSOR 1 |
| 60 KV8-M7131-00X BRACKET,Z SENSOR 1 |
| 61 KV8-M7166-00X PLATE,VALVE 1 |
| 62 KV8-M71V1-01X SENSOR STAY F 1 |
| 62-1 KV8-M71V1-01X SENSOR STAY F 1 Z2 2000.1.24 M9Y0069 |
| 62-2 KV8-M71V1-02X SENSOR STAY F 1 2001.07.18 M170103 |
| 63 KV8-M71V2-01X SENSOR STAY R 1 |
| 63-1 KV8-M71V2-01X SENSOR STAY R 1 Z2 2000.1.24 M9Y0069 |
| 63-2 KV8-M71V2-02X SENSOR STAY R 1 2001.07.18 M170103 |
| 64 KV8-M71V3-00X BRACKET,LOCK SENSOR 1 |
| 65 KV8-M71V4-00X BRACKET,MOTOR 1 |
| 66 KV8-M71V5-00X HOLDER,PULLEY 1 |
| 67 KV8-M71Y1-00X COLLAR 1,PULLEY 1 |
| 68 KV8-M71Y2-00X COLLAR 2,PULLEY 1 |
| 69 KV8-M71Y3-00X BEARING 2 |
| 69-1 90933-01J800 BEARING 2 |
| 69-2 Delete |
| 70 99009-10800 CIRCLIP 1 ISTW-10 |
| 71 KV8-M71Y9-00X BODY,CYLINDER 1 |
| 72 KV8-M71YA-00X VALVE CLUTCH 4 |
| 73 KV8-M71YB-00X PACKING 8 |
| 73-1 90990-22J005 PACKING 8 |
| 74 91317-05006 BOLT HEX.SOCKET HEAD 8 2002.1.8 M210011 |
| 75 KM1-M7105-00X PLUG 2 8 |
| 76 KM1-M7140-00X PACKING 8 MYR-6 |
| 76-1 90990-22J003 PACKING 8 MYR-6 |
| 77 K65-M257M-00X O-RING 3 16 S12.5 |
| 77-1 90200-01J125 O-RING 3 16 S12.5 |
| 78 KM1-M7112-01X STOPPER 1 |
| 79 KM1-M7138-00X BELT HEAD 2 |
| 80 KJ2-M7157-00X BRG. 2 MF128ZZS |
| 80-1 90933-03J128 BRG. 2 MF128ZZS |
| 81 KM1-M7186-00X O-RING 12 5X1.0 |
| 81-1 90990-17J007 O-RING 12 5X1.0 |
| 82 KH4-M7133-00X BRG 2 MR128ZZS |
| 82-1 KJ2-M7157-00X BRG. : MF128ZZS X1 1998.12.16 M010097 |
| 82-2 90933-03J128 BRG 2 MR128ZZS |
| 83 KV8-M653F-E0X SENSOR,3 4 E2S-Q22(CLUTCH) |
| 84 KV8-M653F-A0X SENSOR,3 4 E2S-Q22(DOWN1,3,5,7) |
| 85 KV8-M653G-A0X SENSOR,4 4 E2S-Q22B(DOWN2,4,6,8) |
| 86 KV8-M653H-A0X SENSOR,5 ASSY 8 (POS) |
| 87 KV8-M7160-00X SENSOR,HEAD ASSY 3 |
| 87-1 KV8-M7160-C1X SENSOR H(SAFETY) 3 2004.03.18 M430057 |
| 88 KV7-M653F-20X SENSOR,3 ASSY. 1 L=450 |
| 88-1 KV7-M653F-A0X SENSOR H(R ORG) 1 L=450 2003.01.06 M2Y0087 |
| 89 93604-06083 PIN DOWEL 6 4X6 |
| 89-1 90990-20J001 PIN DOWEL 6 4X6 2002.01.09 M1Y0141 |
| 90 90250-04J08 PIN PARALLEL 8 4X8 |
| 90-1 99480-04008 PIN,PARALLEL X1 2000.10.31 M000129 |
| 91 90110-03248 BOLT HEXA.S.H 7 M3X55 |
| 91-1 91317-03055 BOLT HEX SOCKET HEAD 7 M3X55 2003.07.15 M370057 |
| 92 92D18-02006 BOLT HEX 12 M2X0.4X6 |
| 92-1 90115-02J006 BOLT HEX SOCKET HEAD 12 M2X0.4X6 2002.08.21 M280085 |
| 93 $KM-05 MUFFLER 7 |
| 94 $SLH8-01 JOINT 2 |
| 95 $SLH6-01 JOINT 2 |
| 96 KG2-M7181-00X PACKIN MYA 4 16 |
| 96-1 90990-22J001 PACKIN MYA 4 16 |
| 97 KV8-M7162-00X SOLENOID VALVE(UNIT) 1 |
| 98 KV8-M7163-01X EJECTOR,RESIN 1 |
| 98-1 KV8-M7163-01X EJECTER,RESIN X1 1999.10.28 M990030 |
| 99 KV8-M71V9-00X COVER 2 |
| 100 KV8-M71VA-00X SPACER 4 |
| 100-1 90563-23J060 SPACER 4 2001.10.17 M100045 |
| 101 KV8-M71VB-00X COVER,SENSOR 1 2001.09 M190105 |
| 102 KM1-M4592-12X VAC SENSOR BOARD ASSY 8 |
| 103 KM5-M7174-F0X FILTER CAP 2 |
| 104 K46-M8527-D0X O-RING 2 |
| 104-1 90990-17J008 O-RING 2 |
| 105 KM5-M7174-K0X O-RING 6 |
| 105-1 90990-17J010 O-RING 6 |
| 106 K46-M8527-C0X FILTER 8 |
| 107 KM5-M7174-G0X FILTER CAP 6 |
| 108 KV8-M71RM-00X SLEEVE 4 |
| 109 KV8-M71RL-00X NUT,LOCK 4 |
| 110 KV8-M7106-80X SPACER 1 2003.09.02 M38031 |
| 111 92A08-03303 SET SCREW 16 M3X3 2001.08.30 M180140 |
| 112 92A08-04305 SET SCREW 24 M4X5 1999.12.20 M9Y0071 |
| 113 KM5-M7174-A2X EJECTOR,UNIT 8 No.114+No.115+UNIT |
| 114 KM1-M7163-21X VALVE(BlOW) 8 |
| 115 KM1-M7163-30X VALVE(OPERATE) 8 |
| 116 KV8-M7162-10X VALVE(UP/DOWN) 8 |
| 117 KV8-M7162-20X VALVE(SLOW) 8 |
| 118 KV8-M7160-A1X SENSOR H(N-UP) 1 2004.03.18 M430057 |
| 119 KV8-M7160-B1X SENSOR H(N-DOWN) 1 2004.03.18 M430057 |
| 120 KV8-M71VS-00X COLLAR SENSOR 12 1999.12.21 M9Y0084 |
| 121 KV8-M71VR-00X PLATE NUT |
